SUNWARD SWDM 240FE

Looking for a sturdy and powerful medium excavator around 24 tons which respects the environment?

The Sunward SWE 240FE electric medium excavator is the perfect fit for areas with high requirements in terms of exhaust gas emissions and noise, but also high and cold plateaus, with large temperature differences and insufficient oxygen supply, and finally construction sites in relatively confined spaces underground and tunnels. It is designed to be versatile and durable, with a long lifetime.

The SWE 240FE’s masterful design, 3-Phase asynchronous motor, and enhanced hydraulics system deliver power, smooth operation, and high productivity with respect for environment.

This top‑of‑the‑line medium excavator offers excellent performance, comfortable and safe operation, and convenient maintenance.

In addition to respecting the environment, the SWE 240FE is also a “smart” excavator since it can be equipped with Sunward’s remote control technology, which has the characteristics of long-distance control, ensuring safety and operator efficiency.

After the remote intelligent module is installed, it is more suitable for operations in places with harsh working conditions and significant threats to human health and life, such as demolition in hazardous and explosive environments, the debris removal and salvage work, etc.

Tests have shown that the smart electric excavator developed by Sunward have faster response, greater efficiency and greater performance than combustion engine ones. Thus, the SWE 240FE smart electric excavator can work continuously for more than 6 hours after fully charged, and it only takes 1.5 hours from 5% to 100% charged by two charging guns.

The SWE 240FE is powered by 422.87 kW/h Lithium-ion batteries and a 132 kW three-phase asynchronous motor.

The SWE 240FE is also equipped with all the equipment providing safety and comfort: cameras, all-new generation touch screen, Sunward Smart Fleet remote troubleshooting system and standard GPS, etc.

Discover all the other advantages of the Sunward SWE 240FE.



Operating weight 14 700 kg
Standard bucket capacity 0.6 m³
Shipping length 8 270 mm
Shipping width 2 490 mm
Height over cabin 2 860 mm
Model  Cummins QSF3.8
Emission rating EU Stage V
Displacement 3.8 L
Rated power output 90 kW
Type 2 variable piston pumps
Displacement 2*165 L/min
Hydraulic pressure 31.4/34.3 Mpa
Max. digging depth (2 piece boom) 5 530 mm
Max. digging reach (2 piece boom) 8 330 mm
Max. bucket digging force 100 kN
Max.arm digging force 76 kN
Emission rating

EU Stage V

Operating weight

23 360 kg

Power output

132 kW

Max. digging depth

6 750 mm

Width

2 984 mm

SWE 240FE

Looking for a sturdy and powerful medium excavator around 24 tons which respects the environment? The Sunward SWE 240FE electric medium excavator is the perfect fit for areas with high requirements in terms of exhaust gas emissions and noise, but also high and cold plateaus, with large temperature differences and insufficient oxygen supply, and finally construction sites in relatively confined spaces underground and tunnels. It is designed to be versatile and durable, with a long lifetime. The SWE 240FE’s masterful design, 3-Phase asynchronous motor, and enhanced hydraulics system deliver power, smooth operation, and high productivity with respect for environment. This top‑of‑the‑line medium excavator offers excellent performance, comfortable and safe operation, and convenient maintenance.



Emission rating: EU Stage V
Operating weight: 23 360 kg
Power output: 132 kW
Max. Drillling Diameter: 6 750 mm
Width: 2 984 mm
