SUNWARD SWSL 0607DC

The Sunward SWSL 0607DC is the smallest scissor lift of the DC Series. This electric scissor lift features a zero-emissions electric drive, making it durable and cost-effective. Despite its very compact size, it is very strong. As all the Sunward scissor lifts models, it offers excellent performance, comfortable and safe operation, and it is very nearly maintenance-free. Its size makes it very easy to transport to every jobsite, and, thanks to its zero emissions, it can be used both indoors and outdoor.

Discover all the other advantages of the Sunward SWSL 0607DC.

Propulsion Electric
Driven type Electric
Operating weight 900 kg
Max. working Height 6.5 m
Max. platform height 4.5 m
Ground clearance – Platform elevated/lowered 60 / 17 mm
Machine height -Lowered, rails raised / rails folded 2.06 /1.7 m
Platform height-Lowered 0.95 m
Overall length 1.44 m
Overall width 0.76 m
Platform length 1.29 m
Platform width 0.7 m
Platform extension length 1.29 m
Drivespeed-Platformelevated/lowered 0.8/3.6 km/h
Max. gradeability 30%
Platform Capacity 240 kg
Extension capacity 100 kg
Max. working angle 1.5°/ 3°
Turning radius – Inside / Outside 0.4 /1.6 m
Max. working height

6.5 m

Capacity

240 kg

Machine width

0.76 m

Operating weight

900 kg

Propulsion

Electric

Drive type

Electric

SWSL 0607DC

The Sunward SWSL 0607DC is the smallest scissor lift of the DC Series. This electric scissor lift features a zero-emissions electric drive, making it durable and cost-effective. Despite its very compact size, it is very strong and offers excellent performance, comfortable and safe operation, and it is very nearly maintenance-free. It can be used both indoors and outdoor.

Max. working height: 6.5 m
Capacity: 240 kg
Machine width: 0.76 m
Operating weight: 900 kg
Propulsion: Electric
Drive type: Electric
